D1W Cable Gland

Size : 16mm to 90mm & ½” to 3½”
Standard : BS 6121: Part-1:2005, EN 50262:1999, IEC62444:2010
Function : Providing environmental seal on the inner sheath of cable. Also provides mechanical cable retention & electrical continuity via armoured wire termination in indoor and outdoor area with all types of SWA cable.
Ingress Protection : IP66
Material : Brass CW614N, Stainless Steel 316L
Thread : Metric, NPT
Operating Temp. : -60°C to +125°C
Cable Type : Single Wire Armour (SWA) Cable
Features : Inner Displacement Seal and Armoured Ring Clamping
Seal Material : LSOH Silicone Seal & LSOH Nylon Washer
Accessories : PVC Shroud, Earth Tag, Serrated Washer and Entry Thread Seal.
